T-ONE 6B SLIDING AUTOMATIC GATE KIT
Designed for residential sliding gates the T-ONE 6B is an automatic gate opener for sliding electric gates up to 500kg in weight with built in battery charger. The T-ONE-6B comes in kit form which is complete with wireless receiver, two remote control transmitters and a set of safety photocells.
12 VOLT SLIDING ELECTRIC GATE MOTOR - RESIDENTIAL - 600KG
They don't make them much better than this. Manufactured by TAU in northern Italy the T-ONE 6B is the follow on from the hugely successful Speed2. Like the old Speed2 the new T-ONE is mechanically second to none with quality metal gears and legendary TAU 12 volt motor. The control board has been rebuilt to higher stress levels and now comes complete with built in receiver and also optional battery charger.
Out of the box the T-ONE 6B will come complete with control board all pre wired, built in receiver, two remote control transmitters and a set of quality photocells.
PRICING
TONE6B -
Kit complete two transmitters and set of photocells.
$1311.00
RACK1000 -
Metre length of steel reinforced nylon rack - six fixing lugs.
$24.00
REMTAU -
4 channel 433mhz key ring style remote control.
$66.00
TAUKEYPAD -
TAU wireless outdoor keypad
$268.00
TAUBATTKIT -
Battery backup module and battery
$162.00
SOLAR12.25.26KIT -
25W panel, 26ah battery, regulator
$348.00
SPECIFICATION
Motor Voltage -
12 volts DC
Current Standby -
110mA
Current at use -
1.05A
Motor power -
250W
Maximum thrust -
980N
Operating speed -
14 metres per minute
Maximum gate size -
500 kg
Duty cycle -
100%
Height -
288mm
Width -
308mm
Depth -
202mm
Weight -
13.6 Kg
IP rating -
IP54
DOWNLOAD & MANUALS RESOURCE PAGE
OPTIONAL
RACK - Most sliding gate systems require rack (There are a few chain drive operators for industrial gates). Available in steel reinfoced nylon for gates up to 800 kilograms and a larger galvanised steel version for heavier industrial gates. One metre lengths with easy fix points. Click to view.
PHOTOCELLS - A must have if you use automatic closing function is photocells. Photocells provide an extra level of safety to prevent gates from closing on vehicles or pedestrians. Sliding gates can have a single set between the gate posts or multiple sets if desired at various heights. Click to view.
PHOTOCELLS - A must have if you use automatic closing function is photocells. Photocells provide an extra level of safety to prevent gates from closing on vehicles or pedestrians. Sliding gates can have a single set between the gate posts or multiple sets if desired at various heights. Click to view.
